ML2650 multi-ribbed belt taper sleeve roller, internal thread type
- Hotline: +86 0572-2561676
-
Huzhou Mailong Machinery Co., Ltd.
Professional production and sales of transmission parts
Hotline
+86 0572-2561676
Professional production and sales of transmission parts
Hotline
+86 0572-2561676 Based on the design of 2250 series of products, the tube is moulded with plastic cone sleeve, with low running noise and shockproof.
The plastic multi-wedge belt wheel is installed at the end of the knitting drum, so that the driving and conveying are separated in the region, and the conveying is more stable.
The design of precision ball bearing and plastic inner and outer cover make up the key bearing assembly, which is not only beautiful, but also makes the bobbin run more quietly.
The design of the plastic end cover at the end of the roller can prevent damage to the bearing caused by dust and splashing water to a certain extent.
ISO9982, PJ, groove spacing 2.34mm, a total of 9 grooves. The conveying capacity depends on the transmission arrangement and the type of multi-wedge belt. The weight of the goods suitable for conveying usually does not exceed 30kg.
The roller is light in weight and has good starting performance.
Suitable temperature: -5°C~ + 40°C
Copyright: Huzhou Mailong Machinery Co., Ltd.
Address: No.211 Chuangxin Road, Chengnan Industrial Park, Huzhou City, Zhejiang Province, China
