ML2660 Double groove “O” roller cone roller with internal thread
- Hotline: +86 0572-2561676
-
Huzhou Mailong Machinery Co., Ltd.
Professional production and sales of transmission parts
Hotline
+86 0572-2561676
Professional production and sales of transmission parts
Hotline
+86 0572-2561676 Taking 2260 series as the design basis of the products, the tube is covered with molded plastic cone sleeve, with low operating noise and shockproof.
The plastic "O "belt wheel is installed at the end of the roller to separate the drive from the delivery area, eliminating the possibility of interference between the "O" belt and the delivery of goods.
The design of precision ball bearing and plastic inner and outer cover constitute the key bearing assembly, which is not only beautiful, but also makes the roller run more quietly.
The design of the plastic end cover at the end of the roller can prevent damage to the bearing caused by dust and splashing water to a certain extent.
Since the groove is not rolled on the cylinder body, the cylinder body is not deformed, and the conveying will be more stable.
The load capacity of the roller depends on the drive arrangement and the driving capacity of the "0 "belt.
Suitable temperature: -5°C~ + 40°C
